2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment

2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment
2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment 2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment

Large Image :  2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment

Product Details:
Place of Origin: China
Brand Name: SAILRAY
Certification: CE, CQC, ROHS
Model Number: HS-01
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Carton
Delivery Time: 30 days
Payment Terms: T/T, Western Union
Supply Ability: 500pcs per month
Detailed Product Description
Model: HS-01(3 Cores,2.2m,with RJ11 Connector ) Type: Two Step
Cover Materia: PU Wires Material: Copper
Applications: Electric Control Parts Connector: RJ12
Inner Construction: Omron Micro Switch
High Light:

x ray device

,

mobile x ray unit

3cores 2.2m Two Step X-ray Exposure Omron micro Switch with RJ12 Connector



Performance Parameters( 3cores and 4 cores):

Working Voltage(AC/DC) Working Current(AC/DC) Shell Material Cores
Red Green White
125V/30V 1A/2A White, ABS engineering plastics 1 stage Concentric line 2 stage



Working
Voltage
Working
Current
Shell
Material
Cores
White + Red green + Black
125V 1A White, engineering plastics
1 stage

2 stage

Quick Detail:
Model: HS-01
Type: Two stepping
Construction and material:
with Omron micro switch, PU coil cord cover and copper wires
Wires and coil cord: 3cores or 4cores, 2.2m or 5m
Mechanical life: 1.0 million times
Electrical life: 100 thousand times
Certification: CE, CQC, RoHS
Connector: can fixed to DB9,RJ11,RJ12,RJ45 or Air plug


Description:
X-ray exposure Hand switch is the electric control parts, can be used for controlling the on-off of electrical signal, photographic equipment and medical diagnostic X-ray photography exposure. X-ray exposure Hand switch, used OMRON micro switch as component contacts, is a hand-held switch which has two stepping switches and with fixed trestle.

This type of x-ray exposure hand switch can be 3 cores and 4 cores. The coil cord length can be 2.2m and 5m after fully stretched. Its electrical life can reach to 100 thousand times while its mechanical life can reach to 1.0millioin times.

X-ray exposure Hand switch is comply with the national safety standards: GB15092.1-2003 "the first part of the medical electrical equipments: general requirements for safety" related provisions. Get CE, CQC, ROHSapproval.


Applications:
X-ray exposure Hand switch is the electric control parts, can be used for controlling the on-off of electrical signal, photographic equipment and medical diagnostic X-ray photography exposure






Type and Useful time:

Cores:......................................................................................................three cores, four cores
Type:........................................................................................................ two step
Useful time(Mechanical life): ..............................................................1.0 million times---50 million times
Useful time(Electrical life): .................................................................100 thousand times---300 thousand times


Operation Method:
When pressing the button, it is connected while loosing it is cut. Press the button to the first stage, the first grade is connected. This is for x-ray preparation. Then do not loose your thumb, and press the button to the bottom, the second grade is connected while the first grade remains connected. This is for x-ray operation.


Transportation and Storage Conditions:

Environment Temperature Relative Humidity Atmospheric Pressure
(-20~70)ºC ≤93% (50~106) KPa







Detailed Images

2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment 0

2 Stage Handheld X Ray Device , Engineering Plastics Medical X Ray Equipment 1
